Custom 4 Ways Spring Battery Connector 2.0mm Pitch SMT Right Angle Housing Height 3.8mm

Product Descriptions :

Product name : spring battery contact

Features : surface mount, right angle

Au Plating : 3-5um / customization available

Power : DC12V 2A

Contact numbers : 4 / cusotmization vailable

Contact Resistance: 30mΩ

Insulation Resistance: 500MΩ

Dielectric Withstanding Voltage: 100VAC

Durability: 10,000 Cycle

Insertion Force: 5N to 20N

Extraction Force: 8N to 20N

Operating temperature range: -20°C~+85°C

Recommended IR Reflow(Wave Soldering) Temperature: 260°C

Packaging : tape and reel

We have experienced workers and facilites to 1:1 re-build components as original brand drawings or manufacture prototypes as buyers’ requirements
