USB-B-SD20 USB 2.0 Type B 4Pin DIP Vertical USB B Receptacle

Short Description:

USB2.0 USB-B USB Type-B 4Pin Female connector DIP

Replacement parts : M701-330442 , 690-004-660-023 ,  SS-52300-002 , KUSBVX-BS1N-B , USB-B-S-F-W-VT-R , 5787834-2 , A-USB B-TOP-C


Product Detail

Product Tags

Overview
Quick Details
Model Number:
USB-B-SD20
Type:
USB Type B connector
Place of Origin:
Guangdong, China
Brand:
jinbeili
Packaging:
bag
Description:
USB-B Connector
Current Rating::
1.5A
Voltage Rating::
30V AC
Product Description
Product Name :
USB Type B Female Connector
 Rating :
30V AC , 1.5A
Mounting Angle :
Vertical
HOUSING:
PBT,UL94V-0
SHELL:
BRASS OR SPCC,T=0.50mm
TERMINAL :
:DESCRIPTION:, T=0.20mm
Insulation Resistance:
100MΩ
Dielectric Withstanding Voltage:
500V AC
Insertion Force:
3.5Kgf MAX
Extraction Force:
1.02Kgf MIN
Product Type :
USB Type B
Recommended IR Reflow Temp:
260°C
Operation Temperature Range :
-40°C ~ +105°C

FEATURES :

1, USB TypeB

2, Meet ROHS and REACH standards;3, 30V DC 1.5A4, PCB Board Connector5 ,DIP6 , Right Angle

APPLICATIONS :

1 , Home Appliance

2, Consumer electronics
3, Telecommunications markets

4, Audio / Video products

5, Computer/peripherals

6, , Testing / instrumentation
Spec Sheets



If you need original PDF Format data sheet to refer to , please contact us
