PLB Series RGB ON OFF Type Lock Latching & Non lock Momentary & Alternation Dual LED Illuminated Key Switch for Console
Overview
Quick Details
- Place of Origin:
-
Guangdong, China
- Brand Name:
-
JINBEILI
- Model Number:
-
PLB Series
- Type:
-
SWITCH TACTILE
- Application:
-
electronic watch,electronic toy and others
- Supplier Type:
-
Original manufacturer
- Media Available:
-
datasheet, Photo, EDA/CAD Models
- Brand:
-
tactile switch
- Features:
-
/
- Mounting Feature:
-
Back or Front of Panel
- Size / Dimension:
-
/
- Color:
-
black,biue,yellow and green
- Material:
-
Nylon
- Operating Temperature:
-
/
- Mounting Type:
-
Soldering
- Switch Function:
-
ON-OFF
- Current Rating (Amps):
-
0.05A
- Voltage Rating – AC:
-
/
- Voltage Rating – DC:
-
DC 12V
- Voltage:
-
12V
- Packaging:
-
NO
- Voltage Rating:
-
12V
- Illumination Voltage (Nominal):
-
NO
- Voltage – Switching AC:
-
NO
- Voltage – Switching DC:
-
DC 12V
- Power – Rated:
-
0.6W
- Voltage – Supply:
-
/
- Display Mode:
-
/
- LED Color:
-
/
- Rated Voltage:
-
12V
- Current – Switching:
-
0.05A
- D/C:
-
PLB Series
- Salt Spray Test::
-
NSS 48H(Can be customized according to customer requirements)
- Operating Life::
-
500,000 cycles
Give you better reason to choose us
Spec Sheets
Product parameter
1. Switch Rating：DC 25V 0.5A2. Travel：2.2mm±0.2mm3. Timing: Non-shorting4. Contact Resistance: 50mΩMax5. Insulation Resistance: 100MΩMin6. Dielectric Strength: AC 250V for 1min7. Operating Force: ■200±100 gf □300±100 gf8. Operating Life: 1,000,000 cycles9. Salt Spray Test: NSS 48H(Can be customized according to customer requirements） 10.Operation Temperature Range:-20°C~+70°C 11.Application:Home Appliance, Electronics, Industrial, Audio/Video Products
If you need original PDF Format data sheet to refer to , please contact us
Email:sales06@jblec.com
TEL:+86-592-7390769
Web:www.jblec.com
TEL:+86-592-7390769
Web:www.jblec.com
